Single Station PVC / PP Detergent Bottles Blow Molding Machine

Single Station PVC / PP Detergent Bottles Blow Molding Machine

  • Single Station PVC / PP Detergent Bottles Blow Molding Machine
Single Station PVC / PP Detergent Bottles Blow Molding Machine
Product Details:
Place of Origin: Jiangsu , Faygo
Brand Name: Faygo
Certification: CE & ISO
Model Number: HTII-5L
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: 50,000
Packaging Details: Wooden box , PE film
Delivery Time: 5-8 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 60-75 Days
Contact Now
Detailed Product Description
Material: PE, PP , PVC Station: Single
Dry Cycle: 700 Output Of HDPE: 70
Clamping Force: 60 Water Consumption: 0,2-0.3
High Light:

bottle blow moulding machine

,

plastic bottle production machine


Extrusion blow molding machine for PP Detergent bottles

Product Description :
Product Details :Fully automatic Extrusion blow molding machine HT(II)-5L
Technical Specification :

Max product Volume(L)5
Station Double
Dry cycle(pc/h)700*2
Screw Diameter(mm)70
Screw L/D ratio(L/D)25
Screw drive power(KW)22
Screw heating power(KW)6.8~8.2
NO of heating zone (Screw )(ZONE)3
Output of HDPE(kg/h)70
Hydraulic pump driving power(KW)7.5
Clamping force(KN)60
Platen distance(mm)148~508
Mold moving stroke(mm)400
Max .Size of Mold(W*H)(mm)370*390
Capacity of Accumulator head(L)
Max.Die diameter (Single-head)(mm)145
Die heating power(Single-head)(KW)2.5
No.of heating zone(Single-head)(ZONE)3
Central distance of Bi-head(mm)160,180
Max. Die diameter (Bi-head)(mm)80
No .of heating zone(Bi-head)(ZONE)5
Heating Power (Bi-head)(KW)2.88
Blowing pressure(Mpa)0.6
Air consumption(M^3/MIN)0.4
Cooling water pressure(Mpa)0.2~0.3
Water consumption(L/MIN)60
Size of machine(L*W*H)(m)3.43*2.3*2.65
Weight of machine(TON)5.5

Packaging &Shipping
Packaging Details: PE film ,Wooden box ,Wooden /Steel base
Delievery Detail :By ship or train
Some pictures of sample
Extrusion blow molding machine for Oil lubricant bottlesExtrusion blow molding machine for Oil lubricant bottles


OUR SUPPLIER OF MAIN PARTS
a) Hydraulic parts

NameSupplier
Oil pumpPARKER OR SUNNY ,America
ValveYUKEN OR SUNNY
HOSE,JOINTPARKER SIR
SealerTOP DZ Europe

b)Electrial parts

NameSupplier
Microcomputer control systemMITSUBISHI PLC,JAPAN
Touch Screen HITECHHITECH color screen ,Taiwan
Temperature controllerMITSUBISHI
ConductorSCHNERDER
Air switchSCHNERDER
MotorSIMENS BEIDE Asychronous motor
InverterMITSUBISHI

C)Pneumatic parts

NameSupplier
Solenoid valveFESTO,Germany
CylinderFESTO,Germany

Our company
TONGDA is dedicated to making blow molding machine .we always provide best service and quality for our customers.
Extrusion blow molding machine for Oil lubricant bottles
