    Product Details:

    Place of Origin: China
    Brand Name: Faygo Union Machinery
    Certification: CE& ISO9001
    Model Number: FGS09

    Payment & Shipping Terms:

    Minimum Order Quantity: 1set
    Price: Negotiable
    Packaging Details: Covered by PE film
    Delivery Time: 50-60 working days
    Payment Terms: T/T, L/C, Western Union
    Supply Ability: 15sets per year
    Contact Now
    Detailed Product Description
    Condition: New Plastic Material: PC
    Voltage: 380V 50HZ Screw Design: Single Screw
    Power: 150-300kw Sheet Width: 750-2000mm

    PP PE sheet Extruder plastic production line/Making machine/Extrusion Machinery





    About productions

    The sheet extrusion line is equipped vertical three-roller calender, with high performance vented extruder, die, screen change system, cooling rocket, haul-off unit, cutting unit and etc.

    This kind of line is to produce PE/PP/PS/HIPS/ABS/PVC single-layer and multi-layer sheet with thickness of 0.1mm to 30mm and width of upto 3000mm.



    Features Specifications:

    1) The plasticizing effect of the sheet is very good. After the sheet formed and walking in curved line, it can make sure the stability of the sheet stock.



    2) The heating system is controlled by high-grade china heater, stainless heater, inner-storing type single heating pipe and precision temperature-controlling die mould, is exact in controlling temperature, quickly in heating, good in keeping temperature, long life and save time and energy.



    The screw is made by high precision special digital screw miller; extruding property can be highly harmonized.



    It has firstly introduced advanced technique of producing screws with variable pitch and depth, so that the material can be more softly sheared and cut.



    SJ series single screw extruder is composed of screw and barrel, a power transmission system, heating, cooling and electrical control. Mainly used in PE, PP, ABS, PS, PET pipe, plate, sheet, film, profile, Granulation plastic products such as the mixing and extrusion molding.



    The machine is mainly used in extruding soft and hard thermoplastics, such as polyviyl chloride(PVC),polyethylene and others. It is used with relevant auxiliary machine (including shaping machine head)to produce several kinds of plastic products, for example: film, pipe, rod, plate, thread, cable insulating layer, hollow product. It is also used of prilling.

    .



    About Us Jiangsu Faygo Union Machinery Co., Ltd. Faygo Plast

    1. It is a high-tech enterprise which is specialized in research, manufacture and marketing plastic extrusion lines,plastic production line.



    2. Plastic Extuder is widely used in Plastic industry.It is the main part of Plastic Pipe Extrusion Line, Plastic Profile Extrusion Line,Plastic Recycling Line and Plastic Granulating Line.



    PP foaming sheet
    PP foaming sheet has unique superiority, such as good flexibility, mechanical property, rebound resilience and resistance to deformation. It has a big market in paper file fields and car decoration.



    All SJZ Series Conical Twin-Screw Extruder Technical Parameter:

    Extruder Model SJ120/38,SJ45/30 SJ120/30 SJ100/38,SJ45/30 SJ100/33
    Raw Material PC PP/PE PC PP/PE
    Products thickness (mm) 3-30 2-15 2-10 2-8
    Products Width (mm) 2100 2300 1300 1300
    Capacity (KG/H) 450 400 300 200
    Motor Power (KW) 200,18.5 132 132,18.5

    110





    After sales service

    1> Find our products through our website and Alibaba,GlobalMarket,Made in China,Globalsources,Traderkey.

    2> One year warranty for the whole system.

    3> We can send our engineers/technicians for installation of entire production line . Should make sure the safety of our engineers.

    4> After one year , we can help you to maintain the machine and the accessories are provided only one the cost price.

    5> Every 3 year , we can help to overhaul the machine freely(labor).
