24000BPH PET Bottle Blow Molding Machine Fully Automatic

24000BPH PET Bottle Blow Molding Machine Fully Automatic

24000BPH PET Bottle Blow Molding Machine Fully Automatic
24000BPH PET Bottle Blow Molding Machine Fully Automatic
24000BPH PET Bottle Blow Molding Machine Fully Automatic
Product Details:
Place of Origin: Jiangsu, China
Brand Name: Faygo
Certification: CE, ISO
Model Number: FG6
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD 80000-140000 per set
Packaging Details: covered by PE film
Delivery Time: 50 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 80 sets per year
Contact Now
Detailed Product Description
Bottle Material: PET Bottle Size: 200-2000ml
Capacity: 6000-24000BPH Bottle Diameter: 55-110mm
Bottle Height: 150-310mm Suitable Cap: Plastic Screw Cap
Machine Structure: Linear Type Filling Material: Water, Juice, Beverage
High Light:

24000BPH Bottle Blow Molding Machine


Blow Molding Machine Fully Automatic


PET Blow Molding Machine


24000BPH Bottle Fully Automatic Blow Moulding Machine

1. Machine description

Full automatic blow molding machine is suitable for producing PETplastic containers and bottles in all shapes. It is widely used to produce the carbonated bottle, mineral water, pesticide bottle oil bottle cosmetics, wide-mouth bottle and hot fill bottle etc.


2. Features of main body :

1). Stable performance with advanced PLC.
2). Automatic preform conveyer to save human cost.
3). Preform self-rotation and infrared pre-heater revolution assure the even distribution of heat, which improve the bottle shaping rate, increase the production.
4). High adjusting performance to enable preheat the preforms perfectly by adjust the voltage control area in the PLC, which could adjust the temperature of the infrared lights in the pre-heater, and keep the proper temperature and humidity invariable.
5). High safeties with security automatic-locking device in each mechanical action, which will make the production into a perfect safe environment, in case of the breakdown in certain procedure.
6). Introduce the FESTO air cylinder to avoid contamination and noise.
7). Satisfaction with different atmospheric pressure for blowing and mechanical action by dividing the blowing and action into three parts in the air pressure diagram of the machine.
8). Strong clamping force with high pressure and double crank links to lock the mould.
9). Two ways of operating: automatic and manual.
10). Low cost,high efficiency,easy operation and maintenance etc, profited from the fully automatic technological process.
11). Ideal cooling system make the finished bottles without any flaws.

Want to know more message , contact us with out hesitate ! Inquiry us now !


24000BPH PET Bottle Blow Molding Machine Fully Automatic 0

24000BPH PET Bottle Blow Molding Machine Fully Automatic 1


3. Machine model details

Model FGF4 FGF6 FGF8 ...
capacity(500ml) 6000-7200BPH 9000-10000BP 12000-13000BPH ...
Max volumn(ml) 2000 2000 750 ...
Max bottle height(mm) 328 328 300 ...
Max bottle diameter(mm) 105 105 75 ...
Bottle neck size(mm) 20-25 20-25 20-25
Max preform length(mm) 150 150 140 ...


4. What you can get from our machine

1) Up to 45% less by heating

In our blower, preform distance is only 38mm, with fewer lamps, you can heat more preforms.

2) Up to 20mins change mould

What if you change mould like open&close a drawer?

With our special quick-mould-change design, mould can find position itself. And be changed within 20mins.

3) Up to 30% less by air

The machine is fully driven by servo motor, no need low pressure air.

We also decrease the dead volumn in the blowing station to reduce high pressure air consumption.

4) Up to 80% less maintain cost

Changing new air cylinders and steal rings is main maintain cost in blower. We adopt servo motors, it is more reliable and almostt no need maintain cost.

24000BPH PET Bottle Blow Molding Machine Fully Automatic 2
