Special Designed Custom Molding Machine For Toys Children Safe
| Place of Origin | CHINA |
|---|---|
| Brand Name | HUAYU |
| Certification | CE ,SGS |
| Model Number | HYBM-Special designed |
| Minimum Order Quantity | 1SET |
| Price | Negotiate |
| Packaging Details | EXPORT PACKAGED |
| Delivery Time | 4MONTHS |
| Payment Terms | L/C, T/T |
| Supply Ability | 40SETS PER YEAR |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Brand Name | Huayu | Material | HDPE |
|---|---|---|---|
| After-sales Service Provided | Service Machinery Overseas | Warranty | 12months |
| Power (kW) | 580 | Weight (T) | 45T |
| Key Selling Points | Long Service Life, Easy To Operate | Applicable Industries | Energy & Mining, Hotels, Home Use, Machinery Repair Shops, Manufacturing Plant, Restaurant, Other |
| Application | Plastic Product | ||
| Highlight | Special Designed Custom Molding Machine,HDPE Custom Molding Machine,HDPE extrusion blow molding machine |
||
Product Description
Hdpe Extrusion Machine Blow Mold Machine Well-Designed For Children Safe Toy
PRODUCT DETAILS
Voltage
380 V/50 Hz or customized
Dimension(L*W*H)
11*5.4*6.2m
Hollow part volume
200-1000L
PLC Brand
Siemens
Screw L/D Ratio
28
Screw diameter (mm)
80 mm
Screw Heating Power(kW)
128 kW
Extruder Motor Power(kW)
37 kW
Mold Platen Size(Width)(mm)
1500 mm
Mold Platen Size(Height)(mm)
1700 mm
Air Pressure(MPa)
0.8 MPa
Air Comsumption(m³/min)
1.5 m³/min
Q&A:
Q2: what is the warranty period of your machine?
Answer: The free charge guarantee term is 12 months after the installation and adjustment in your factory.
Q3: what if my machine damaged doing the warranty period?
Answer: firstly, our engineer will help you to diagnose the problem via online guidance. if any parts damaged during the warranty period, we will send the parts to you for replacement free of charge. If you can not fix he problem by replacement of the new parts, we will send engineer to your factory to help fixing the machine.
Q4: what is the delivery time of your machine?
Answer: Normally it would take about 90-120 days to complete the machine.The specific time needs to be based on your machine.
Q5: can you provide us the machine drawings and technical proposal?
Answer: yes. After receiving your detailed requirement and product drawings, our engineer will come out with the suitable
technical proposal with the basic machine concept drawings to you. Be size after you placing the order we will send you the more detailed technical configuration of the machine to you for confirmation. Only after you confirming the technical configuration then we will start the manufacturing process.
Q6: what’s your payment terms?
Answer: we can accept the following payment terms: T/T, L/C, Alibaba .
Q7: how can we install the machine?
Answer: you provides the invitation letter for visa applying once the machine to be shipment. We’ll dispatches one engineer and one English interpreter to your factory once the machine arrive your factory or as the your request.
