Composite Wood Plastic Profile Production Line Extrusion Machine Double Screw

    • Composite Wood Plastic Profile Production Line Extrusion Machine Double Screw
    • Composite Wood Plastic Profile Production Line Extrusion Machine Double Screw
  • Composite Wood Plastic Profile Production Line Extrusion Machine Double Screw

    Product Details:

    Place of Origin: China
    Brand Name: Faygo Union Machinery
    Certification: CE
    Model Number: FG15

    Payment & Shipping Terms:

    Minimum Order Quantity: 1set
    Price: Negotiable
    Packaging Details: PE film
    Delivery Time: 60 working days
    Supply Ability: 48sets/year
    Contact Now
    Detailed Product Description
    Name: Wood Plastic Composite Profile Extrusion Machine Voltage: 380v 50hz
    Original: China Screw Design: Conical Twin Screw
    Raw Material: PVC Output: 40-160kg/h
    Color: Can Be Designed

    Composite Wood Plastic Profile Production Line Extrusion Machine Double Screw



    Wood plastic composite profile extrusion machine  introduction are below:



    This production line uses the special designed scew and barrel, die and manufacturing technique to produce wooden plastic products. The series of equipments are one step thick wooden plastic board extrusion machine, one step wooden plastic profile extrusion machine, wooden plastic decoration plate extrusion machine, wooden plastic pellet extrusion machine etc.

    The machine can produce PE, PP or PVC and wooden plastic products, which are mainly applied for making pallets, floors, outdoor decoration materials and other wide applications.



    Wood plastic composite profile extrusion machine flow chart:



    SJZ Series Conical Twin Screw Extruder→ Die mould → Vacuum Calibration Table → QYQ series Haul-offs and Cutting Machine Unite→DF series Stacker → Control cabinet.



    Wood plastic composite profile extrusion machine Parameters:



    Models YF180 YF240 YF300 YF600
    Max. of product(mm) 180 240 300 600
    Extruder Model SJZ55/110 SJZ65/132 SJZ65/132 SJZ80/156
    Extruder Power(kw) 22 30/37 37 55
    Cooling Water(m3/min) 5 7 7 10
    Compressed Air 0.2 0.3 0.3 0.4

    The profile making machine usually can separate into YF180, YF240, YF300 and YF600. If your profile width under 180mm you can use our YF180, if your profile width under 200mm, you should choose YF200 and so on.
