Horizontal Automatic PET Stretch Blow Moulding Machine For Mineral Water Bottles

Horizontal Automatic PET Stretch Blow Moulding Machine For Mineral Water Bottles

    • Horizontal Automatic PET Stretch Blow Moulding Machine For Mineral Water Bottles
    • Horizontal Automatic PET Stretch Blow Moulding Machine For Mineral Water Bottles
    • Horizontal Automatic PET Stretch Blow Moulding Machine For Mineral Water Bottles
  • Horizontal Automatic PET Stretch Blow Moulding Machine For Mineral Water Bottles

    Product Details:

    Place of Origin: Zhangjiagang, China
    Brand Name: Faygo Union Machinery
    Certification: CE, ISO
    Model Number: FG-4

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: Negotiable
    Packaging Details: covered by PE films
    Delivery Time: 60 working days
    Supply Ability: 40 sets per year
    Contact Now
    Detailed Product Description
    Material: PET Preform Capacity: 6500-8000BPH
    Total Installation Power: 51kw Heating Power: 25kw
    Machine Size: 3.3*1*2.3m Machine Weight: 3500kg
    Bottle Volumn: 200ml-2L Cavity Number: 4 Cavity
    Type: Water Bottle Manufacturing Machine

     Economical PET preform stretch blowing machine for mineral water bottles



    Generally introduction of our FG4 blowing machine:



    FG4 is the totally new generation of linear blowing machine. Compared with the convetional blowing machine, It has two main charactristics:


    1) High speed: China first Linear blowing machine whose single mold speed can reach 1800 BPH. FG4 has 4 cavities, production speed can reach 7200BPH.
    2) Energy saving: The new modularized design make the machine work more efficient



    FG4 blowing machine parameter:



    Type FG4 FG6 FG8
    Bottle Specifications Mould number(piece) 4 6 8
    Max capacity(BPH) 6500-8000 9000-10000 12000-13000
    maxi volume (mL) 2000 2000 2000
    maxi height (mm) 328 328 328
    maxi diameter (mm) 105 105 105
    preform Specifications Suitable inner bottle neck (mm) 20-25 20-25 20-25
    preform max length (mm) 150 150 150
    Electricity Total installation power (kw) 51 51 97
    Voltage / frequency (V / Hz) 380v,50hz 380v,50hz 380v,50hz
    Air compressor Pressure(bar) 30 30 30
    Capacity(m³/min) 4-6 4-6 4-6
    Mold water pressure(bar) 4-6 4-6 4-6
    Suitable temperature range (℃) 6-13 6-13 6-13
    Flow (L / min) 45 45

    45



    Oven water pressure(bar) 4-6 4-6 4-6
    Suitable temperature range (℃) 6-13 6-13 6-13
    Flow (L / min) 22 22 22
    Machine Specification host machine dimension (m) (LxWxH) 3.3X1.2.3 4.3X1X2.3 4.8X1X2.3
    Weight (Kg) 3200 4000 4500



    One Step Station Services



    1) Stand-by engineers team to provide overseas installation and commissioning service.

    ​2) 1year warranty. During warranty, we provide free of charge for repairing cost.

    ​3) Lifetime maintaince. After-sales department can provide life long maintaince service.



    FAQ:



    Q: Your company is a transactional company or an industrial manufacture factory?

    A: We are an industrial manufacture factory which locates in Zhangjiagang city.



    Q:All of your products are made by your self or compacted via purchasing the others?

    A: We have independent technical team who focus on making machines, all the products are made by our technical team.



    Q:What is the ability of your factory?

    A:About 200 machines per year.



    Q:Do you have any other services about your products?

    A:We have a lot of experience on making projects and specifications for our clients, also we have a fixed service system.



    Q:How do you make the quotation for clients?

    A:The price depends on quality and performance but the clients should be satisfied first.
