3000L 10-Layer Co-Extrusion Water Tank Blow Molding Machine with PLC Control System
| Place of Origin | CHINA |
|---|---|
| Brand Name | HUAYU |
| Certification | ISO9001 CE |
| Model Number | HYBM3000-10 |
| Minimum Order Quantity | 1 SET |
| Price | 440000 |
| Packaging Details | be disassembled into many parts for container transportation |
| Delivery Time | 4 MONTHS |
| Payment Terms | L/C,T/T |
| Supply Ability | 1SET 120DAYS |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Control System | PLC | Mould Material | Aluminum |
|---|---|---|---|
| Screw Diameter | 80/80/80/80/80/80mm | Machine Dimensions | 10*5.5*7m |
| Average Consumption | 180kw | Air Switch | Schneider |
| Mould Cavity | Single/Double | Maximum Air Pressure | 0.8Mpa |
| Die Head Weight | 26T | Applicable Material | HDPE |
| Average Power | 540kw | Automation Level | Fully Automatic |
| Power | 138 KW | Machinery Test Report | Provided |
| Inverter | Siemens | ||
| Highlight | 3000L Capacity Water Tank Blow Molding Machine,10-Layer Co-Extrusion Blow Molding Machine,PLC Control System Water Tank Molding Machine |
||
You can tick the products you need and communicate with us in the message board.
Product Description
3000L 10-Layer Multi-Functional Water Tank Blow Molding Machine with Recirculating
This versatile 3000L capacity blow molding machine with 10-layer co-extrusion is engineered for producing a diverse range of plastic products. The integrated water tank system provides continuous, efficient cooling to minimize downtime and maximize production efficiency. With its multi-functional design accommodating various product shapes and sizes, this machine serves multiple industries. The user-friendly interface and automated controls ensure straightforward operation, while the durable water tank design offers easy maintenance and long-term reliability.
Auto Feeder System
| Component | Specification | Features |
|---|---|---|
| Hopper material | Stainless steel | Stable performance, easy maintenance |
| Feeding type | Vacuum loaded | |
| Feeding motor | 2.2/2.2/2.2kw |
Extrusion System Specifications
| Component | Specification | Features |
|---|---|---|
| Screw diameter | 130/150/130mm | Nitrided 38CrMoAIA |
| Screw L/D ratio | 28:1 | Special designed screw ensures uniform material plasticizing and efficiency |
| Extruder motor | 110/132/110kw | |
| Reducer | 375/420/375 | Premium Chinese brand offering long life and low noise operation |
| Screw heating power | 5.5kw*16 | |
| Plasticizing capacity | 1000kg/h |
