1000L 9-Layer Large Eco-Friendly Water Tank Blow Molding Machine with Purification Cooling System
| Place of Origin | CHINA |
|---|---|
| Brand Name | HUAYU |
| Certification | ISO9001 CE |
| Model Number | HYBM1000-9 |
| Minimum Order Quantity | 1 SET |
| Price | 280000 USD |
| Packaging Details | be disassembled into many parts for container transportation |
| Delivery Time | 4 MONTHS |
| Payment Terms | T/T,L/C |
| Supply Ability | 1SET 120DAYS |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Power | 105 KW | Extruder Motor Power | 55kW |
|---|---|---|---|
| Use | Water Tank | Average Aonsumption | 280KW |
| Power Source | Electric | Plc Brand | Siemens |
| Capacity | 1000-5000 Liters | Applicable Material | HDPE |
| Automation Grade | Automatic | Attribute | Drawings Customize |
| Parison Control | MOOG 200point | Color | Customizable |
| Showroom Location | None | Gear Box | Guomao |
| Machine Dimensions | 10*5.5*7m | ||
| Highlight | 1000L eco-friendly water tank machine,9-layer blow molding water tank machine,water tank machine with cooling system |
||
You can tick the products you need and communicate with us in the message board.
Product Description
Focused on sustainability, this 1000L capacity blow molding machine with 9-layer co-extrusion features a water tank system that ensures clean and efficient cooling water circulation. This eco-friendly design reduces environmental impact and enhances the machine's longevity. The machine is equipped with advanced technologies for precise temperature control and consistent product quality, making it an excellent choice for environmentally conscious manufacturers. The water tank is designed for easy maintenance and long-term reliability, making this machine a cost-effective and efficient solution for your production needs.
|
Auto Feeder |
||
|
hopper material |
stainless steel |
Stable performance, easy maintenance |
|
feeding type |
spring loaded |
|
|
feeding motor |
2.2kw |
|
|
Extrusion System |
||
|
Screw diameter |
120mm |
Nitrided 38CrMoAIA |
|
Screw L/D ratio |
28:1 |
special designed screw can ensure the material plasticizing uniform and efficient |
|
Extruder motor |
90kw |
|
|
Reducer |
330 |
Best quality brand in china ,long life and low noise |
|
Screw heating power |
5kw*5 |
|
|
Plasticizing capacity |
250kg/h |
|
