2000L 8-Layer Large Energy-Saving Water Tank Blow Molding Machine with High-Efficiency
| Place of Origin | CHINA |
|---|---|
| Brand Name | HUAYU |
| Certification | ISO9001 CE |
| Model Number | HYBM2000-8 |
| Minimum Order Quantity | 1 SET |
| Price | 320000 USD |
| Packaging Details | be disassembled into many parts for container transportation |
| Delivery Time | 4 MONTHS |
| Payment Terms | T/T,L/C |
| Supply Ability | 1SET 120DAYS |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Max Volume | 35L | Air Pressure | 0.8MPa |
|---|---|---|---|
| Temperature Control | PLC Module | Gear Box | Guomao |
| Material | HDPE | Clamping Force | 1800KN |
| After Sales | OVERSEAS SERVICE | Machinery Test Report | Provided |
| Cleaning Method | Easy Cleaning | Automation Level | Fully Automatic |
| Cooling Water Pressure | 0.3-0.6MPa | Contactor | Schneider |
| Motor | Siemens | Die Head Heating | 60KW |
| Range | 500-2000L | ||
| Highlight | 2000L water tank blow molding machine,8-layer energy-saving blow molding machine,high-efficiency water tank molding machine |
||
You can tick the products you need and communicate with us in the message board.
Product Description
This energy-saving blow molding machine with a 2000L capacity and 8-layer co-extrusion is designed to optimize energy usage. The water tank system ensures rapid and effective cooling, reducing energy consumption and operational costs. The machine's advanced control system provides precise control over the molding process, ensuring high-quality products. Its durable construction and reliable performance make it suitable for large-scale production environments. The water tank is designed for easy maintenance and long-term reliability, making this machine a cost-effective and efficient solution for your production needs.
|
Extrusion System |
||
|
Screw diameter |
90mm*2 ,100mm*4 |
Nitrided 38CrMoAIA |
|
Screw L/D ratio |
28:1 |
special designed screw can ensure the material plasticizing uniform and efficient |
|
Extruder motor |
45kw*2,55kw*4 |
|
|
Reducer |
ZLYJ-250*2, 280*4 |
Best quality brand in china ,long life and low noise |
|
Screw heating power |
4kw*24 |
|
|
Plasticizing capacity |
700kg/h |
|
|
die head |
||
|
Accumulator capacity |
60kg |
designed by ourselves and get the patent |
|
Die diameter |
According to products |
|
|
Die head heating power |
140kw |
|
