Automatic 5-Layer 1000L Extrusion Blow Molding Machine for Water Tanks
| Place of Origin | CHINA |
|---|---|
| Brand Name | HUAYU |
| Certification | ISO9001 CE |
| Model Number | HYBM-200-1000L,5layers |
| Minimum Order Quantity | 1SET |
| Price | 260000 USD |
| Packaging Details | be disassembled into many parts for container transportation |
| Delivery Time | 4 Months |
| Payment Terms | T/T,L/C |
| Supply Ability | 1SET 120DAYS |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Voltage | Pending | Total Power | 402kw |
|---|---|---|---|
| Average Power | 220kw | Machine Dimension (L*W*H) | 8*9*6.5 |
| Productivity | 16-25pcs/h | Screw Diameter | 80/80/80/80/80mm |
| Screw L/D Ratio | 28：1 | Accumulator Capacity | 35kg |
| Die Diameter | According To Products | Max. Mould Size | 1200*1500mm(W*H) |
| Maximum Air Pressure | 0.8Mpa | Air Consumption | 1.5m3/min |
| Highlight | 6-Layer Extrusion Blow Molding Machine,1000L Blow Moulding Machine,Automatic Water Tank Blow Moulding Machine |
||
Product Description
Automatic 5-Layer Extrusion Blow Molding Machine (1000L)
Our 1000L 5-Layer Blow Molding Machine represents the pinnacle of engineering excellence, designed for manufacturers who demand superior quality containers and optimal production performance.
Key Features
- Multi-Layer Construction: 5-layer structure enables strategic material placement for lighter, stronger, and more cost-effective finished products with enhanced performance characteristics.
- High-Capacity Production: Engineered for maximum yield with robust components designed for consistent, high-quality output in demanding 24/7 production environments.
- Advanced Control System: Intuitive operation with cutting-edge control technology providing precise oversight and customization for optimal production orchestration.
Hydraulic System Specifications
| Main Oil Tank Capacity | 890L |
| Main Oil Pump | Gear Pump 125CC |
| Main Oil Pump Motor | 37kW |
| Servo Oil Tank Capacity | 200L |
| Servo Oil Pump Model | Plunger Pump 22 |
| Servo Oil Pump Motor | 7.5kW |
Electronic System Specifications
| Main Operation Panel | Touch Screen 9" |
| Control System | PLC |
| Thickness Control Points | 200 Points |
| Temperature Control | PLC Module |
This machine features a servo motor system for reduced energy consumption, high efficiency, and low noise operation, providing a significant competitive advantage for your manufacturing operations.
