3 Layer 200 Ltr Automatic Blow Molding Equipment With 132KW Extruder Motor

  • 3 Layer 200 Ltr Automatic Blow Molding Equipment With 132KW Extruder Motor
  • 3 Layer 200 Ltr Automatic Blow Molding Equipment With 132KW Extruder Motor
  • 3 Layer 200 Ltr Automatic Blow Molding Equipment With 132KW Extruder Motor
  • 3 Layer 200 Ltr Automatic Blow Molding Equipment With 132KW Extruder Motor
  • 3 Layer 200 Ltr Automatic Blow Molding Equipment With 132KW Extruder Motor
Place of Origin Cnina
Brand Name Huayu
Certification CE ,SGS,ISO1900
Model Number HYBM220L-DL
Minimum Order Quantity 1SET
Price Negotiate
Packaging Details WELL PACKAGED
Delivery Time 4MONTHS
Payment Terms L/C, T/T
Supply Ability 40SETS PER YEAR

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Capacity Range 220L Machine Dimension 8.2*5.2*5.8M
Average Consumption 130KW Total Power 300KW
Accumulator Capacity 20KG Extruder Motor 132KW
Screw Diameter 130MM Screw L/D Ratio 30:1
Plasticiaing Capacity 300KG/H
Highlight

200 Ltr automatic blow molding equipment

,

3 Layer automatic blow molding equipment

,

132KW blow moulding machine manufacturers
Leave a Message
Product Description
Huayu 120L, 200L, 220L HDPE water tank blow molding machine. The service advantages are as follows:
Pre-sales: Thoroughly comprehend the diverse needs of customers, assist them in selecting the appropriate type of blow molding machine and auxiliary equipment, and rationally plan customers' water, electricity, gas, and oil solutions.
During sales: Deploy professional technical engineers to help equipment operators to install and connect the water and electricity of the blow molding machine and auxiliary equipment, ensuring that the equipment can operate in a standardized and safe manner. We also offer training for machine operators to enable them to operate the blow molding machine skillfully and grasp the maintenance of the equipment.
After-sales: Supply customers with lifetime technical guidance and continuous optimization of products.
3 Layer 200 Ltr Automatic Blow Molding Equipment With 132KW Extruder Motor 0

MACHINE DETAILS

Name
200L double L ring drum machine



Material
HDPE



Blow Moulding Type
Extrusion Blow Moulding



After-sales Service Provided
Service Machinery Overseas



Parison Control
MOOG 200point



Certification
CE ISO



Advantages
servo motor remote control



Layer
3 layers



CONTROLLER
PLC+Touch Screen



Hydraulic Valve
Yuken
Clamping Force (kN)
1200
Output (kg/h)
450 kg/h


3 Layer 200 Ltr Automatic Blow Molding Equipment With 132KW Extruder Motor 13 Layer 200 Ltr Automatic Blow Molding Equipment With 132KW Extruder Motor 23 Layer 200 Ltr Automatic Blow Molding Equipment With 132KW Extruder Motor 33 Layer 200 Ltr Automatic Blow Molding Equipment With 132KW Extruder Motor 43 Layer 200 Ltr Automatic Blow Molding Equipment With 132KW Extruder Motor 53 Layer 200 Ltr Automatic Blow Molding Equipment With 132KW Extruder Motor 6











3 Layer 200 Ltr Automatic Blow Molding Equipment With 132KW Extruder Motor 73 Layer 200 Ltr Automatic Blow Molding Equipment With 132KW Extruder Motor 83 Layer 200 Ltr Automatic Blow Molding Equipment With 132KW Extruder Motor 9
